AIRENGINE5773-23HW Dual-Band WIFI Access Point Optical Electrical Wall Plate Wi-Fi 7 Ap

AIRENGINE5773-23HW Dual-Band WIFI Access Point Optical Electrical Wall Plate Wi-Fi 7 Ap — a wireless access point supplied by GNX Systems for enterprise and business IT infrastructure deployments in Dubai, UAE. Model/part reference: AirEngine5773-23HW. Contact GNX Systems for full technical specifications, compatibility details, warranty terms, and a competitive quote.

Key Specifications:
Installation Type: Wall
Ceiling
Junction Box
Dimensions without packaging (H x W x D) [mm(in.)]: 160 mm x 86 mm x 38 mm (6.30 in. x 3.39 in. x 1.50 in.)
Dimensions with packaging (H x W x D) [mm(in.)]: 73 mm x 203 mm x 114 mm (2.87 in. x 7.99 in. x 4.49 in.)
Weight without packaging [kg(lb)]: 0.39 kg (0.86 lb)
Weight with packaging [kg(lb)]: 0.53 kg (1.17 lb)
Storage: NAND Flash 256 MB
Console port: BLE console
Maximum power consumption [W]: 14.2 (excluding USB)
Maximum heat dissipation [BTU/hour]: 46.0 BTU/hour
Power supply mode: PoE (hybrid cable)
DC power adapter
Rated input voltage [V]: 12 V
Input voltage range [V]: 12 V ± 10%
PoE: 802.3af/at
Service port surge protection: PoE port:
Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B
Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion B
Maximum number of physical ports on the entire device: GE (RJ45) x 4, supporting 10M/100M/1000M auto-sensing
2.5G/GE (LC) optical port x 1 (The AP has a built-in BIDI optical module, which connects to an optical fiber through the LC port. The wavelength on the AP side is TX 1310 nm/RX 1490 nm, with the transmit optical power of -9 dBm to -3 dBm and the receive optical power of -15 dBm to -3 dBm. The peer end must use an optical module with the wavelength of TX 1490 nm/RX 1310 nm and the matching power. It is recommended that the optical fiber routing distance be within 2 km.)
Long-term operating temperature [°C(°F)]: 0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [°C(°F)]: -40°C to +70°C (-40°F to +158°F)
Long-term operating relative humidity [RH]: 5% RH to 95% RH, non-condensing
Long-term operating altitude [m(ft.)]: -60 m to +5000 m (-196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa]: 53kPa – 1
